Product description:Gseries axial flow fan is a product that’s used in frequency control motors and developed by our factory according to the development trend of motor industry. Our factory was the manufacturer with the earliest development and the most complete specifications, and the products are promoted and used by motor industry nationwide with good feedback. This series of fan is composed of three parts, namely, the main case, motor and fan blade. The motor adopts the structure of outer rotor, which has the advantages such as high efficiency, low noises, simple structure and convenient installation etc.


G series axial flow fan is mainly used in the forced air cooling of frequency control motor and the ventilation in other sites, like the pipe and equipments etc.

parameter

型号	电制	功率(W)	转速(r/min)	风量(m3/h)	全压(pa)	噪声dB(A)	风叶直径(mm)
G-80A	三相380V.50Hz	60	2800	350	60	62	150
G-90A	三相380V.50Hz	60	2800	500	80	65	169
G-100A	三相380V.50Hz	60	2800	650	82	67	186
G-112A	三相380V.50Hz	60	2800	1000	110	70	210
G-132A	三相380V.50Hz	40/60	1400/2800	450/1000	30/70	68/70	250
G-160A	三相380V.50Hz	40	1400	960	40	70	300
G-180A	三相380V.50Hz	230	1400	1200	55	70	340
G-200A	三相380V.50Hz	230	1400	1800	65	72	380
G-225A	三相380V.50Hz	230	1400	2750	82	74	430
G-250A	三相380V.50Hz	230	1400	3300	85	76	470
G-280A	三相380V.50Hz	370	1400	4000	110	76	530
G-315A	三相380V.50Hz	450	1400	5200	150	77	600
G-355A	三相380V.50Hz	250	900	4700	70	75	680

install

型号	D1	D2	L1	L2	L3	δ	a	R	n
G-80A	150	155	8	32	147	1.5	4	3	3
G-90A	169	175	6	36	151	1.5	4	3	3
G-100A	186	193	20	62	177	1.5	5	3.5	3
G-112A	210	217	22	62	177	1.5	5	3.5	3
G-132A	250	258	22	72	187	1.5	5	3.5	3
G-160A	300	314	36	92	207	2	5	3.5	4
G-180A	340	352	42	97	259	2	5	3.5	4
G-200A	380	393	47	117	279	2	6	4.5	4
G-225A	430	443	52	119	281	2	6	4.5	4
G-250A	470	482	57	154	316	2	6	4.5	4
G-280A	530	546	68	175	389	2	9	5.5	4
G-315A	600	614	72	178	392	2	9	5.5	4
G-355A	680	694	82	185	400	2	7	6.5	4
